Rctimer HP4215 630KV 18N24P Multirotor Brushless Motor

HP4215-630kv
Price:
USD
$29.99
$33.99
    Please select the information you wantX
Quantity:
-
+
(829 available)
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
  • Description
  • Reviews(1)

Configuration  18N24P
KV- 630KV
The no load current:0.75 Amp
Battery: 2-6S



RCTimer High Performance(HP) Series brushless motor built from high quality components:
1. The magnet specification is 40 uh.
2. The bearing is NSK(Japan), it can support a long life.
3. 0.20mm laminations, maximum efficiency and minimum Eddy Current losses.
4. Ultra-flexible motor leads with high-temp 220 °silicone rubber.
5. 3.5mm bullet connectors already installed.
6. With rotor dynamic balance process,



Feature:


1. NSK bearing.
2. 0.20mm laminations.
3. Dynamic balance

Test 1  Quadrotor 4 motors:

Motor 2: kV 664, R 0.092, NL Current 0.81Amps;
Motor 3: kV 656, R 0.097, NL Current 0.77Amps;
Motor 4: kV 663, R 0.115, NL Current 0.76Amps;
